SansAmp GED-2112 Specifications
Note: With on-going product development and improvements, specifications and/or
the cosmetic appearance of this unit may change without prior notice. Replacement
parts are available, i.e., knobs, rack handles, faceplate, etc. For more information,
please contact Tech 21.
Model Number: GED-2112
Input Impedance- Front Input: 1MOhm
Input Impedance-Inputs A & B: 1MOhm
Output Impedance-1/4” SansAmps: 1KOhm min
Output Impedance-XLRs: 600 Ohms min
Input Level-Front Input: 1V RMS max
Input Level-Inputs A & B: 1V RMS or 10V max, with -20dB pad engaged
Output Level-XLRs: Switchable to -20dB or 0dB range
Effects Loop Send: 1K Ohm min, -20dB
Effects Loop Return: 100K Ohm min, -20dB
Low Frequency Response: 10Hz or better*
High Frequency Response: Harmonic content, 20kHz or better*
Maximum Power Consumption: 5 Watts
AC Input Power (factory set): 100V, 117V, 230V, 240V
Cycles: 50/60 Hz
NOTE: Each unit constructed for specific voltages. AC power cannot be switched.
Enclosure: Aluminum and steel, fully shielded
Dimensions: 19.0"w x 1.75"h x 5.25"d / Overall depth: 6.25"
Weight: 5 lbs.
*Due to the variety of amplifier emulations available, frequency response
characteristics will vary.
