ULTRA CLEAN LUBRICATED COMPRESSOR
INSTALLATION
2
3. CONNECTIONS
Electrical Connection
to disconnect and
electrical panel
220 v
(110 v / 220 v ) on the
single models only.
Air Out
Connection to building
supply line.
Alternate Air
Connection
to fresh air supply.
Figure 2
Dryer Purge
Connection
