10/29/2019 Tech Works CI-Series Systems Planning & Installation Manual Page 7 of 42
MJ-1 - Microphone Jack
The MJ-1 Microphone wall jack assembly is made available to make installation of
the PRO-42 and PRO-45 microphones easier. It is a 3 pin XLR jack mounted on a
white plastic deco plate with a single gang trim ring. A 6-inch wire pigtail is soldered
to the XLR jack so that the filed technician can terminate the field wire without
providing a soldering iron.
PRO-SGM - Shotgun Microphone Assembly
The PRO-SGM is a shotgun microphone assembly which includes a wall
plate, jack, cord, and gimble mount, so it easily mounts to a wall or ceiling
and can be easily directed toward the audio source. A 6-inch wire pigtail is
soldered to the XLR jack so that the filed technician can terminate the field
wire without providing a soldering iron. Everything you need is included for
proper installation.
PRO-ODM - Operator Desk Microphone
Our PRO-ODM Operator desk microphone can be used in a remote location where
someone may not have a headset but still needs to contribute to the conversation.
HM-1 Omni-Directional Hidden Microphone
Our HM-1 omni-directional hidden microphone mounts to a simple wall plate and is very
effective for observation areas.
We’ve selected the best and most popular 25V speakers to pair with the products we build.
The System 2 is a wall mount speaker
The System 21 is a round ceiling mount speaker which includes a backbox and
all required mounting hardware.
The System 5 is a ceiling speaker which replaces a standard size
acoustic ceiling tile.
