06/29/17 ICA-202D OPERATION AND INSTALLATION MANUAL Page 3 of 32
List of Illustrations:
Page
Functional Diagram 5
Mechanical Drawings 8
Front View 9
Rear View 10, 11, & 19
Simplified Block Diagram 12
PCB Jumper Locations 13
Audio Chain Block Diagram 17
Integrated System Block Diagram 19
Operator Reach Controls, Stepped Buttons 21
Basic Two Station Template 23
Basic Prison Intercom Setup 24
Basic Prison/PLC Interface Applications 25
Multi-Master Prison/PLC Intercom 26
Fiber Optic Cable Remote Audio 27
VOIP Interface to Remote Prison Cells 28
Dukane / Rauland Replacement 29
Intercom with Recording and Paging 30
ICA-202D-WM1 Single Wall Mount 31
ICA-202D-WM2 Dual Wall Mount 31
ICA-202D-RM1 Rack Mount 31
ICA-202D-RM2 Rack Mount 31
Accessories 32
