10
DISPLAYPORT TO HDMI/VGA ADAPTER
EN
5.0 OPERATION
1) Connect DisplayPort of this product to a DisplayPort source device
2) Connect HDMI port of this product to an HDMI monitor
3) Connect VGA port of this product to a VGA monitor
6.0 CONNECTION DIAGRAM
DisplayPort Source
HDMI
Cable
VGA
Cable
HDMI Monitor VGA Monitor
