Techly ICOC DSP-VH12 - Package Contents; Specifications

9
DISPLAYPORT TO HDMI/VGA ADAPTER
EN
3.0 SPECIFICATIONS
Signal Inputs/Output
Input Connector DisplayPortMalex1
Output Connector
1xHDMIFemaleHDMIV1.4
1xVGAFemale(MaxVGA1920x1200)
Resolutions
HDMI Resolutions Upto4KX2K@30HZ
VGA Resolutions Upto1920X1200@60HZ
Mechanical
Size(L-W-H)
60×42×14MM main part
Cablelength=150mm
Weight(Net) 39g
Environmental
Operating Temperature 0°C to +45°C
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature -10°Cto+70°C
Storage Humidity 5%to90%RH(nocondensation)
Power Requirement DPCableprovidepowerforproduct
Power consumption
Current consumption of connecting the TV or
monitor directly
HDMIoutput<400mA
VGAoutput<400mA
NOoutputdevice<20mA
Accessories Adapter
UserManual
4.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are
contained in the shipping carton:
• Mainunitx1
• UserManualx1
