HDMI 2.0 EXTENDER OVER CAT.6/7 CABLE 4K
8
EN
HDMI 2.0 EXTENDER OVER CAT.6/7 CABLE 4K
EN
IntroductIon
This HDMI Extender includes a transmitter unit and a receiver unit, allows HDMI signal to be
transmittedupto60 meters at4Kx2K@30Hzandupto 30metersat4Kx2K@60Hzlong away via
asingleCAT6/6A/7cableinapoint-to-pointconfiguration.ItsupportsIRpassbackwithawideIR
frequency20-60KHz.Itisperfectforapplicationofoutdooradvertising,videoclips,monitorsystem,
home entertainment and conference, etc.
FEaturEs:
1.SupportHDMI2.0,compatiblewithHDCP2.2
2.Highestresolutionupto4Kx2K@60HZ
3.TransmissionoversingleCAT6/CAT6A/7
4.SupportIRpassbackfunction(IRrangesupport20~60KHz)
5.Transmissiondistanceisupto60meterswhen4K@30Hzand30meterswhen4K@60Hz
6.Metalhousing,stableanddurable
7.Plugandplay
PacKagE contEnts
• Transmitterunitx1pc
• Receiverunitx1pc
• PowersupplyDC5V/1Ax2pcs
• User‘smanualx1pc
• IRBlasterExtensioncablex1pc
• IRReceiverExtensioncablex1pc
InstaLLatIon rEQuIrEMEnts
1.HDMIsourcedevice(computergraphicscard,DVD,PS3,HDmonitoringequipmentetc).
2.HDMIdisplaydevicelikeSDTV,HDTV,andprojectorwithHDMIport.
3.NetworkcablesUTP/STPcat6/6A/7networkcables,whichfollowingthestandardofEIA-568B.
