INSTALLATION REqUIREMENTS
1.Source:HDMIvideosource,suchasDVD,PS3,STB,PC,Etc.
2.Display:HDTV,projectororotherdisplaywithHDMIport
3.Cable:UTP/STPCat6/6A/7cable,followingEIA/TIA568B
PANEL DESCRIPTION
1. Transmitter unit (TX)
➊

DC5Vpowerinput
➋
HDMIsignalinput
➌
IRsignaloutputtoconnectwithblasterextensioncable
➍
Resetbutton
➎
RJ45signaloutput
➏
HDMIsignalindicatorled:itlightsonallthetimewithHDMIsignal
input, flashes with no signal input
