Techly IDATA EXTip-314 - Specification

EN
10
1) Connect HDMI input transmitter with HDMI output of source
device.
2) ConnectIRblasterextensioncabletotheIRextenderoutport.
3) ConnectRJ45portwithRJ45inputportofHDMIextenderRX.
4) Connect HDMI output of HDMI extender RX to HDMI input of
HDTVandsetTVsourceinputtocorrectHDMIinputchannel.
SPECIFICATION
HDMI signal CompatiblewithHDCP
Transport protocol HDbitT
Support resolutions
480i@60Hz,480p@60Hz,
576i@50Hz,576p@50Hz
720p@50/60Hz,
1080i@50/60Hz,
1080p@50/60Hz
Transmit distance
Upto120mtransmissionfor
1080p60HzfullHDoversingle
Cat6
IR signal Support20-60kHzIRdevice
Input 1xHDMI
Output 4xRJ45(IDATAEXTIP-314)
8xRJ45(IDATAEXTIP-318)
Connection indicator led 4xled(IDATAEXTP-314)
8xled(IDATAEXTIP-318)
Working temperature 0°C~60°C
Power supply (trasnsmitter) DC12V@3A
Power consumption <24W
Dimension (transmitter)
299(W)x110.7(D)x29.6
(H)mm
Weight (transmitter) 430g
Color Black
HDMI Extender Splitter over CAT6 with IR
