Techly IDATA EXTip-314 - Connection and Operation

EN
9
Reset
button
HDMI
input
IR blaster
extension
port
Signal
link LED
RJ45 output Power input
(DC5V)
CONNECTION AND OPERATION
Network cable
FollowsthestandardEIA-568B:
1-Orange/white
2-Orange
3-Green/white
4-Blue
5-Blue/white
6-Green
7-Brown/white
8-Brown
CONNECTION
Tasto reset
Ingresso
HDMI
Porta
di estensione
IR blaster
LED
connessione
segnale
Uscita RJ45 Ingresso
alimentazione
(DC5V)
HDMI EXTENDER TX
(Sender)
HDMI EXTENDER
RX
(R eceiver)
DVD
T V T V
T V T V
Cable
HDMI Extender Splitter over CAT6 with IR
HDMI Extender Splitter over CAT6 with IR
