Techly IDATA EXTIP-314V4 - Connection and Operation

Reset
button
HDMI
input
IR blaster
extension
port
Signal
link LED
RJ45 output Power input
(DC5V)
CONNECTION AND OPERATION
Network cable
Follows the standard EIA-568B:
1- Orange/white
2- Orange
3- Green/white
4- Blue
5- Blue/white
6- Green
7- Brown/white
8- Brown
CONNECTION
Tasto reset
Ingresso
HDMI
Porta
di estensione
IR blaster
LED
connessione
segnale
Uscita RJ45 Ingresso
alimentazione
(DC5V)
HDMI EXTENDER TX
(Sender)
HDMI EXTENDER
RX
(R eceiver)
DVD
T V T V
T V T V
