Adattatore HDMI tipo D a VGA
HDMI D Type to VGA Adapter
EN
HDMI D Type to VGA Adapter
Dear customer
Thank you for purchasing this product. For
optimum performance and safety, please read
these instructions carefully before connecting,
operating or adjusting this product. Please keep
this manual for future reference.
1.0 INTRODUCTION
This kind of HDMI D Type to VGA converts digital HDMI signal into analog VGA video. when you watch movies or play
games on traditional VGA monitors or projectors,this product not only can allow you to enjoy their high definition image
,butalsocanletyouenjoythehighqualityofsound.Besides,IftheHDMISourcescan’tsupplytheenoughpower,you
can connect your power adapter or computer to the Micro USB female for charging.
1.1 FEATURES
Thisproducthasmanyfeaturesthatenableittoperforminasuperiormanner.Amongthosefeaturesyouwillfind:
•EasytoUse:Installinseconds,noneedofsetting.
• Conversion: It can convert complete HDMI into VGA
video.
•SupportsHDCP1.2.
•Supports165MHz/1.65Gbpsperchannel(6.75Gbpsall
channel)bandwidthforHDMIInput.
• Supports Analogue Video output up to UXGA and
1080pwith10-bitDAC.
2.0 SPECIFICATIONS
Signal Inputs/Output
Input Video Signal 0.5-1.0voltsp-p
InputDDCSignal 5voltsp-p(TTL)
Input connection HDMIDFemale
Output connection VGA
HDMI video input format 480p/576p/720p/1080p
VGA video output format 480p/576p/720p/1080p
Operating Frequency
VerticalFrequencyRange 50/60Hz
Input Video Amplifier Bandwidth 1.65Gpbs/165MHz
Mechanical
ShellSize(L-W-H) 45X43X14.5MM
Weight(Net) 27g
Environmental
Operating Temperature 0°to+70°
Operating Humidity 10%to85%RH(nocondensation)
Storage Temperature -10°to+80°
Storage Humidity 5%to95%RH(nocondensation)
Power Requirement
ExternalPowerSupply NO
Powerconsumption(Max) 2W
Regulatory Approvals
ConverterUnit FCC,CE
Accessories Adapter
ACPowerAdapter EUstandard
User Manual
Note:Specificationsaresubjecttochangewithoutnotice.
