ABOUT THIS PRODUCT
ThisAVtoHDMIconverterisdesignedtoconvertaudioandvideo
signalsfromvideosourcedevicessuchasDVD,UHSTapeDeckandSet
Top Box into HDMI signals that you can view on a HDTV. Making video
comealive,deliveringthesharpest,mostrealisticHDvisualsavailable.
FEATURES
• AVsignalsconverttoHDMIsignals
• SupportsNTSCandPALstandardTVformatsinput
• SupportsHDMI1080por720poutput
• Minisize,portableandflexible
• Plugandplay,easyinstallation
PACKAGE CONTENTS
• AVtoHDMIconverter
•User’smanual
•PowersupplyDC5V/0.5A
PANEL DESCRIPTION
INSTALLATION REQUIREMENTS
Source devices
•SourcedevicewithRCAjacks,suchasVCD/DVDplayer,STBetc.
Display devices
•DisplaydevicewithHDMIinput,suchasSDTV,HDTV,projectoretc.
①
② ③ ④
①
② ③ ④
3
WWW.TECHLY.COM
AV TO HDMI
CONVERTER
1 VIDEOL/R
The yellow jack input the video signal, the red
and the white jack input the audio signal - right
and left channel
2 720/1080P Switchtheresolutionto720por1080p
3 HDMI OutputHDMIsignal
4 DC5V InputDC5Vpower
