Technaxx TX-103 User Manual

12
1 Tone Arm / 2 Cue Lever
Replacing the Stylus
It is recommended that the stylus is replaced as soon as you notice
a change in the sound quality. Prolonged use of a worn-out stylus
may damage the record. Wear and tear on the stylus will be
accelerated when playing 78 RPM records.
A: Removing the stylus from the cartridge
Place a screwdriver at the tip of the stylus heads hell and push
downwards in the direction shown in sketch “A”. Remove the stylus
head shell by pulling it forwards and pushing downwards.
B: Installing the new stylus
Hold the tip of the stylus head shell and insert it by pressing in the
direction illustrated by “B”. Push the stylus head shell upwards in the
direction illustrated by “C” until the stylus locks into the tip position.
(1) Guide pins inside

Technaxx TX-103 Specifications

General

Type	Belt-drive audio turntable
Operation	Semi Automatic
Motor type	DC motor
Product color	Black, Gold
Cartridge type	Ceramic stereo cartridge
Volume control	Rotary
Cassette player	Yes
Turntable speeds	33, 45, 78 RPM
Supported radio bands	AM, FM
Audio formats supported	MP3, WMA
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, SD, SDHC
Signal-to-Noise Ratio (SNR)	45 dB
USB version	2.0
Bluetooth range	8 m
Bluetooth version	2.0+EDR
Bluetooth profiles	A2DP, HFP
USB ports quantity	1
Power supply type	AC
AC adapter frequency	50 Hz
AC adapter output voltage	230 V
Power consumption (typical)	18 W
Impedance	4 Ω
Frequency range	60 - 16000 Hz
RMS rated power	2.5 W
Number of speakers	2

Weight and Dimensions

Depth	445 mm
Width	335 mm
Height	235 mm
Weight	7000 g
