Technaxx TX-103 User Manual

6
5 Stereo speakers (one on each side, 2x 2.5W)
6 Function Knob: Rotate the knob to select Phono, CD
(/USB/SD/BT), AUX/Tape or Radio
7 Power 8 Compact Disc Tray
9 Band: Select
AM/FM in RADIO
mode
10 Tuning Knob: Tune to a radio
station in RADIO mode
11
3.5mm Earphone
jack
12 3.5mm AUX-IN jack
13
Volume knob 14 Open/Close CD tray
15
“ << ” Press to select previous track or press and hold to fast
CD/USB/SD/BT reverse
16
“ >> ” Press to select next track or press and hold to fast
forward in CD/USB/SD/BT modes
17
Play/Pause: Playback in CD/USB/SD/BT mode. The Play
Indicator illuminates during playback of CD/USB/SD
18
USB port 19 SD card slot
20
Tape operation button
Eject/Fast Forward cassette
21
Cassette Tray 22 Dust Cover

Technaxx TX-103 Specifications

General

Type	Belt-drive audio turntable
Operation	Semi Automatic
Motor type	DC motor
Product color	Black, Gold
Cartridge type	Ceramic stereo cartridge
Volume control	Rotary
Cassette player	Yes
Turntable speeds	33, 45, 78 RPM
Supported radio bands	AM, FM
Audio formats supported	MP3, WMA
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, SD, SDHC
Signal-to-Noise Ratio (SNR)	45 dB
USB version	2.0
Bluetooth range	8 m
Bluetooth version	2.0+EDR
Bluetooth profiles	A2DP, HFP
USB ports quantity	1
Power supply type	AC
AC adapter frequency	50 Hz
AC adapter output voltage	230 V
Power consumption (typical)	18 W
Impedance	4 Ω
Frequency range	60 - 16000 Hz
RMS rated power	2.5 W
Number of speakers	2

Weight and Dimensions

Depth	445 mm
Width	335 mm
Height	235 mm
Weight	7000 g
