11. Package Contents
Easy Security Camera Set TX-28, 1x Wireless camera, Wireless Video 7” TFT LCD
Receiver, USB-to-Mini-USB-cable (for connection to a PC), Cinch cable, Power
adapter for the camera, Power adapter for the receiver, Screws and dowels, User
Manual
12. Technical Specifications CAMERA
Channels 2400 – 2483.5 MHz
Sensor 1/4” OV7725 CMOS
Resolution 420 TVL
Degree of protection IP65
Min. illumination 0 LUX (IR on)
Ø Lens / Effective Pixel Ø 6mm / 640 (H) x 480 (V)
S/N Ratio More than 48 dB
Video Output 1 Vp-p / 75 Ohm
Power supply 5V / 1A
Operating temperature approx. –5°C up to +45°C
Weight / Dimensions 270 g / (L) 9,5 x (W) 6,8 x (H) 5,7 cm
13. Technical Specifications WIRELESS RECEIVER (Monitor)
Display 7” TFT LCD
Video Format NTSC / PAL
Compression Format MPEG-4
Video input / Video output 4CH wireless single / 1 composite output
Audio input / Audio output 4CH wireless single / 1 composite output
Frame rate
640 x 480 VGA with 20fps
320 x 240 QVGA with 25fps
Memory card MicroSD card up to 32GB
Transmission range ≥ 200m (open range)
Power supply DC 12V / 1A
Operating temperature approx. 0°C up to +50°C
Weight / Dimensions 395 g / (L) 20,0 x (W) 12,0 x (H) 2,0 cm
