Technicolor TG789vac v2 How To Set Up

4. If you wish to connect a device hardwired, you will need to use the Yellow Ethernet
Lead provided with the router and connect it to one of the 4 ETH ports available.
5) Once all of the cables have been connected, you are now able to switch on the power
on the router, leave the router for 10-15 minutes and once all of the lights are on like
shown below, you are able to start using your broadband with Call Flow.
Please Note:
1) The
Red Ethernet
port labelled WAN should not be used
2) It is recommended that for your main computer you use the main Ethernet port which
is labelled ETH1.

Technicolor TG789vac v2 Specifications

General

USB Ports	1 x USB 2.0
Wi-Fi Protected Setup (WPS)	Yes
VoIP	Yes
Firewall	Yes
Frequency Bands	2.4 GHz
Ethernet Ports	4 x Gigabit Ethernet
DSL Type	ADSL2+/VDSL2
DSL Port	1 x RJ11
Security Features	WPA2
