10. Printed Circuit Board Diagram
11. Type Illustration of ICs, Transistors and Diodes
12. Wiring Connection Diagram
13. Block Diagram
14. Troubleshooting Guide
15. Terminal Function of ICs
15.1. IC451 (M38504M6200F): / System Control
Pin
No.
Terminal
Name
I/O Function
1
V
cc
I Power supply terminal
2 VREF I Reference voltage input
3
AV
SS
- GND terminal
4 SYNC I Power failure detect signal input
5 SUBQ I Sub-code Q data signal input
6 SQCK O Sub code Q resistor clock signal
output
7 BLKCK I Block clock signal input
8 CD REQ I Serial communication signal to
Sound Processor (Request
signal input)
9 B CS O Serial communication signal to
Sound Processor (Chip select
signal output)
10 B CLK O Serial communication signal to
Sound Processor (Clock signal
output)
11 DATA O O Serial communication signal to
Sound Processor (Data signal
output)
12 DATA I I Serial communication signal to
Sound Processor (Data signal
input)
13 TEST I
Test mode select signal input /
(Connected to V
CC
via resistor)
14
RESTSW
I Rest switch signal input
15
CNV
SS
-
Connected to V
SS
16 SERVO
RST
O Reset signal output for CD servo
IC
39
