Ref. No. Part No. Part Name & Description Pcs Remarks
306 RME0258 SPRING 1
307 RME0261 SPRING 1
308 RML0516 LEVER 1
309 RML0517 LEVER 1
310 RML0518 LEVER 1
311 RML0519 LEVER 1
312 RML0520 TRAY LOCK 1
313 RML0521 REAR LOCK 1
314 RML0525 FRONT LOCK 1
315 RML0530 LEVER 1
316 RMM0201 SLIDE PLATE 1 1
317 RMM0202 SLIDE PLATE 2 1
318 RMB0551 SPRING 1
319 RMB0553 SPRING 1
320 RMQ0747 UPPER HOOK 1
321 RMQ0749 UPPER SPINDLE 1
322 RMX0140 DISC SPACER 5
323 RMX0141 SPACER 1
324 RHM245ZA MAGNET 1
325 RMR0334 MAGNET HOLDER 1
326 RMR0624-W2 CLAMPER 1
327 RMR1121-K MECHANISM COVER 1
328 RXQ0561 TRAY BASE 1
329 RDG0430 GEAR,RELAY A 1
330 RDG0431 GEAR,RELAY B 1
331 XTV2+6G SCREW 2
332 RMB0552 SPRING 1
333 RME0262 SPRING 1
334 RME0263 SPRING 1
335 RML0526 SPRING 1
336 RMQ0742 SPINDLE BASE 1
337 RMB0550 SPRING 1
338 RML0522 LOADING STOPPER 1
339 RMQ0743 SPINDLE SHAFT 1
340 RMQ0744 LOWER HOOK 1
341 RMQ0745 LOWER SPINDLE 1
342 RMQ0746 UP/DOWN BASE 1
343 RXQ0595 MOTOR 1
344 XTB3+10J SCREW 11
345 RDG0424 GEAR,DRIVE 1
346 RDG0425 GEAR,CHANGE 1
347 RDG0426 GEAR,UP/DOWN 1
348 RDG0427 GEAR,TRAVERSE CAM 1
349 RDG0428 GEAR,TRAVERSE RELAY 1
350 RDG0429 GEAR,PULLEY 1
351 RME0109 FLOATING SPRING(1) 2
352 RME0142 FLOATING SPRING(2) 1
353 RMR1124-K TRAVERSE CHASSIS 1
354 RMS0632 TRAVERSE FIXED PIN 3
355 XTN2+6G SCREW 1
356 RMQ0748 GEAR HOLDER 1
C1 ECEA1CKS101 16V 100U 1
C2 ECBT1E103ZF 25V 0.01U 1
48
To Next Page
