By combining front, center and surround speakers, you can enjoy
the SURROUND mode which conveys a feeling of presence or the
3 STEREO mede which conveys a feeling of orientation.
S URR 0 UND
By reproducing the feeling of depth and movement of sound, video
software or compact discs recorded with Dolby Surround provide
the listener with a feeling of presence like that of a movie theater.
To enjoy SURROUND, be sure to connect the surround speakers.
Front
speaker (L)
Center
speaker
Front
speaker (R)
3 STEREO
You can enjoy audio/video sources with clear sound, more pres-
ence and a good feeling of orientation. 3 STEREO can be used with
non DOLBY SURROUND recordings.
To enjoy 3 STEREO, be sure to connect the center speaker.
Center
speaker
Front
speaker (L)
Surround
speaker (L)
i , i
* it _l
Lj..-
Front
speaker (R)
Surround
speaker (R)
..-r-,
i, LI _
IL ,i
L'_ i i
--L.
I Manufectured under license from Dolby Laboratories Licensing
Corporation. Additionally licensed under Canadian patent num-
ber 1,037,877.
"Dolby", the double-D symbol _t'l and "Pro Logic" are trade-
marks of Dolby Laboratories Licensing Corporation.
Setting the center mode
For Dolby Pro Logic systems, center mode setting is necessary to
play back bass sounds effectively.
Set the center mode in accordance with the size of your center
speaker.
1 2
I
o o o L.-i-l"ll-l-}
.Ol
L.J
........ .........r;ress0OLeYeRoLOaiCto
PRO LOGIC
turn on the Pro
Dolby Logic
system and select the desired
mode.
When the button is pressed, the current
mode is displayed.
Pressing it again changes the Dolby Pro
Logic mode.
For SURROUND mode
i-- I i i--'l /--..j l--i i Ill I T'I
I _1 Hi'l =i I_.H .JJ I
i
Displayed for approximately 1 second
only.
For 3 STEREO mode
/_3 S TE,'2EL?_='""`°
I
Displayed for approximately 1 second
only.
_ ""'tEaR "_E" Press cEi_Ti_R"MODE io ...........
select the correct center
mode.
When the button is pressed, the current center mode is
displayed.
Pressing it again changes the center mode.
NORMAL
When the center speaker is smaller than the front
speakers
WlDEBAND
When the center speaker is the same or larger size as
the front speakers
PHANTOM
When no center speaker is connected.
In the PHANTOM model the sound which would have
been sent to the center speaker will be divided equally
between both the !eft and fight front speakers.
