Fig.4 .
ACP P.C.B.
- Remove the ACP P.C.B. mounting screws ( 4 pcs.) as shown in
Fig.4 .
FAJ P.C.B.
- Remove the FAJ P.C.B. mounting screws ( 8 pcs.) as shown in
Fig.4 .
JACK P.C.B.
- Remove the JACK P.C.B. mounting screws ( 3 pcs., 2 pcs. and
3 pcs.) as shown in Fig.4 .
ASUB P.C.B.
- Release the claws and pull off the ASUB P.C.B. as shown in Fig.4 .
Fig.4
