Technics SX-KN6500

11.8. Removing the keyboard unit
1. Follow the item 11.1..
2. Remove the keyboard unit mounting screws ( 5 pcs.) as shown
in Fig.15 .
3. Place the keyboard cabinet bottomside down, and open the top
cabinet.
4. Remove the keyboard unit holding screws ( 3 pcs.).
Fig.15
- As shown in Fig.16 , the keyboard unit can be anchored in the metal
projection.
Fig.16
11.9. Removing the Disk Drive Unit
1. Follow the item 11.8..
2. Remove the Disk Drive unit mounting screws ( 4 pcs. ) as shown
in Fig.17 .
Fig.17
17
