Technics SX-PC25

Ref. No. Part No. Part Name & Description Pcs Remarks
D13 MA8033H DIODE 1 MAIN [SPC]
D14 MA111TX DIODE 1 MAIN [SPC]
D14 MA165 DIODE 1 MKB1 [SPC]
D15 MA111TX DIODE 1 MAIN [SPC]
D15 MA165 DIODE 1 MKB1 [SPC]
D16 EK04W DIODE 1 MAIN [SPC]
D16,17 MA165 DIODE 2 MKB1 [SPC]
D17 MA8051L DIODE 1 MAIN [SPC]
D18-25 MA165 DIODE 8 MKB1 [SPC]
D18-25 MA111TX DIODE 8 MAIN [SPC]
D26 MA111TX DIODE 1 MAIN [SPC]
D26-88 MA165 DIODE 63 MKB1 [SPC]
D89-176 MA165 DIODE 88 MKB2 [SPC]
F1 XBA1C25NU100 FUSE,2.5A 1
ACP(P,PC) [SPC]
F1 XBA2C12TB0 FUSE,T1.25A 1
ACP(X,XS,XT) [SPC]
F1 XBA2C12TB0 FUSE,T1.25A 1
ACP(XD,XA) [SPC]
F2 XBA2C06TB0 FUSE,T630MA 1 ACP(X,XS,XT,XD,XA) [SPC]
F3 XBA2C06TB0 FUSE,T630MA 1 ACP(EB,EX,EZ,EG,GN) [SPC]
IC1 QCPL-260L IC 1 MAIN [SPC]
IC1,2 HD74LS138P IC 2 MKB1 [SPC]
IC2 T93CU44F1B17 IC 1 MAIN [SPC]
IC3 D97315GD201 IC 1 MAIN [SPC]
IC2,3 HD74LS138P IC 2 MKB2 [SPC]
IC4 M5218AL IC 1 MAIN [SPC]
IC5 M5256DFP10VL IC 1 MAIN [SPC]
IC6,C7 M5218AFPE3 IC 2 MAIN [SPC]
IC8 AN7194K-LD IC 1 MAIN [SPC]
IC9 PCM1734EB IC 1 MAIN [SPC]
IC10 QSIGX3C32003 IC 1 MAIN [SPC]
IC13 M5F7805L IC 1 MAIN [SPC]
JK1 QJJG008AA JACK,AUX IN R/L 1 MAIN [SPC]
JK1 SJJG100A JACK,HEADPHONE 1 HPVOL [SPC]
JK2 QJSG007AA JACK,PEDAL IN 1 MAIN [SPC]
JK2 SJJG100A JACK,HEADPHONE 1 HPVOL [SPC]
JK3 QJSG016AA JACK,MIDI IN/THRU 1 MAIN [SPC]
JK3 SJVD0203B JACK,AC IN 1
ACP [SPC]
JK4 QJSG016AA JACK,MIDI IN/THRU 1 MAIN [SPC]
L1 QLQGT3T131LA 130UH×3 1 MAIN [SPC]
L1 QLQGT3T131LA 130UH×3 1 HPVOL [SPC]
L2 QLQGT2T100LA 10UH×2 1 ACP [SPC]
L2 QLQGT3T131LA 130UH×3 1 MAIN [SPC]
L3 QLQGT1B800GA COIL 1 MAIN [SPC]
L4-L6 QLQGT3T131LA 130UH×3 3 MAIN [SPC]
P1 QPGG0483AA PACKING CASE 1 [SPC]
PCB1 SXPG235411 SW P.C.B. 1 (RTL) [SPC]
PCB2 SXPG235511B HPVOL P.C.B. 1 (RTL) [SPC]
PCB3 SXPG235541A ACP P.C.B. 1 (RTL) [SPC]
