Ref. No. Part No. Part Name & Description Pcs Remarks
PCB4 SXPG235311 MAIN P.C.B. 1 (RTL) [SPC]
PCB5 SXPG218231 PKB P.C.B. 1 (RTL) [SPC]
PCB6 SXPG231111A MKB1 P.C.B. 1 (RTL) [SPC]
PCB7 SXPG231111B MKB2 P.C.B. 1 (RTL) [SPC]
PCB8 SXPG235511A ACP P.C.B. 1 (RTL)(X,XS,XT,XD,XA) [SPC]
PCB8 SXPG235521A ACP P.C.B. 1 (RTL)(P,PC) [SPC]
PCB8 SXPG235531A ACP P.C.B. 1 (RTL)(EX,EB,EZ,EG,GN) [SPC]
Q1,Q2 2SB709AR TRANSISTOR 2 MAIN [SPC]
Q3 2SD601AQ TRANSISTOR 1 MAIN [SPC]
Q4 2SB709AR TRANSISTOR 1 MAIN [SPC]
Q5 2SD601AQ TRANSISTOR 1 MAIN [SPC]
Q6 2SC1815TPE2 TRANSISTOR 1 MAIN [SPC]
Q7 2SA1015TPE2 TRANSISTOR 1 MAIN [SPC]
Q8 2SD601AQ TRANSISTOR 1 MAIN [SPC]
Q9 2SC1815TPE2 TRANSISTOR 1 MAIN [SPC]
Q10 2SA1015TPE2 TRANSISTOR 1 MAIN [SPC]
Q11 2SC1815TPE2 TRANSISTOR 1 MAIN [SPC]
Q12 2SA1015TPE2 TRANSISTOR 1 MAIN [SPC]
Q13 2SD601AQ TRANSISTOR 1 MAIN [SPC]
R1 ERG1SJ100E 1W 10 1 HPVOL [SPC]
R1 ERJ6GEY0R00V 1/10W 0 1 MAIN [SPC]
R2 ERG1SJ100E 1W 10 1 HPVOL [SPC]
R2 ERJ6GEYJ101V 1/10W 100 1 MAIN [SPC]
R3 ERG1SJ100E 1W 10 1 HPVOL [SPC]
R3 ERJ6GEYJ101V 1/10W 100 1 MAIN [SPC]
R4 ERG1SJ100E 1W 10 1 HPVOL [SPC]
R4 ERJ6GEYJ471V 1/10W 470 1 MAIN [SPC]
R5 ERDS2TJ102 1/4W 1K 1 HPVOL [SPC]
R5 ERJ6GEYJ221V 1/10W 220 1 MAIN [SPC]
R6 ERJ6GEYJ104V 1/10W 100K 1 MAIN [SPC]
R7 ERJ6GEYJ103V 1/10W 10K 1 MAIN [SPC]
R8 ERDS2TJ472 1/4W 4.7K 1 PKB [SPC]
R8 ERJ6GEYJ103V 1/10W 10K 1 MAIN [SPC]
R9,10 ERDS2TJ472 1/4W 4.7K 2 PKB [SPC]
R10 ERJ6GEYJ471V 1/10W 470 1 MAIN [SPC]
R11 ERJ6GEYJ223V 1/10W 22K 1 MAIN [SPC]
R12 ERQ2CJP220S 22 1 MAIN [SPC]
R13 ERJ6GEYJ223V 1/10W 22K 1 MAIN [SPC]
R14 ERJ6GEYJ102V 1/10W 1K 1 MAIN [SPC]
R15 ERJ6GEYJ104V 1/10W 100K 1 MAIN [SPC]
R16 ERJ6GEYJ102V 1/10W 1K 1 MAIN [SPC]
R17 ERJ6GEYJ221V 1/10W 220 1 MAIN [SPC]
R18 ERJ6GEYJ102V 1/10W 1K 1 MAIN [SPC]
R19 ERJ6GEYJ331V 1/10W 330 1 MAIN [SPC]
R20 ERJ6GEYJ103V 1/10W 10K 1 MAIN [SPC]
R21 ERJ6GEYJ222V 1/10W 2.2K 1 MAIN [SPC]
R23 ERJ6GEYJ151V 1/10W 150 1 MAIN [SPC]
R24 ERJ6GEYJ104V 1/10W 100K 1 MAIN [SPC]
R25 ERD25FVJ4R7 1/4W 4.7 1 MAIN [SPC]
R26,27 ERJ6GEYJ220V 1/10W 2.2K 2 MAIN [SPC]
R28 ERJ6GEYJ103V 1/10W 10K 1 MAIN [SPC]
R29 ERJ6GEYJ101V 1/10W 100 1 MAIN [SPC]
