6. DISASSEMBLY INSTRUCTIONS
6.1. Removing the top cover
1. Remove the top cover mounting screws (A × 6 pcs.) as shown in
Figure-5 .
2. Lift up the top cover (as shown by the arrows).
6.2. Removing the keyboard cover
1. Remove the top cover (see step “Removing the top cover ”).
2. Release the spring from the shaft.
3. Remove the guide rail lids from the guide rails.
4. Match the gears of the keyboard cover with the notches in the
guide rail, and lift up the keyboard cover as shown in
Figure-5 .
