Technics SX-PR603

Ref. No. Part No. Part Name & Description Pcs Remarks
D213,14 ERA1502V5 DIODE 2 MAIN
D215-17 MA111TX DIODE 3 MAIN
D218 MA8051LTX ZENER 1 MAIN
D219 MA111TX DIODE 1 MAIN
D220,21 MA152WK DIODE 2 MAIN
D301,02 MA121TX DIODE 2 MAIN
D303 MA159ATX DIODE 1 MAIN
F1 XBA1C40NB100 T4A 125V 1
ACP
F1 XBA2C31TB0L T3.15A 250V 1
ACP(X XA XD XT XS ONLY)
F2,F3 XBA2C16TB0L T1.6A 250V 2
ACP(EXCEPTP PC)
IC1 M37471M2196S 8BIT MICRO COMPUTER 1 CPL
IC1 M37471M2196S 8BIT MICRO COMPUTER 1 CPR
IC1 M5218AL OPAMP 1 AS
IC1 SVIGTLP513 PHOTO COUPLER 1 JACK
IC1 TC74VHC138F 3 TO 8 DECORDER 1 MAIN
IC2 D74HC138P DECODER 1 MKB1
IC2 HD74LS07P HEX BUFFER 1 CPL
IC2 HD74LS07P TTL 1 CPR
IC2 M5218AL OPAMP 1 AS
IC2 MN103002A 32 BIT MICRO COMPUTER 1 MAIN
IC3 D74HC138P DECODER 1 MKB2
IC3 HD74LS07P HEX BUFFER 1 CPL
IC3 HD74LS07P TTL 1 CPR
IC3 M5218AL OPAMP 1 AS
IC3 TC7SU04FT85L INVERTER 1 MAIN
IC4 D74HC138P DECODER 1 MKB2
IC4 IMIFS781BZBD CLOCK GEMERATOR 1 MAIN
IC4,C5 M5218AL OPAMP 2 AS
IC5 T7SZ32FUT85L INPUT OR GATE 1 MAIN
IC6 M5218AL OPAMP 1 AS
IC6 TC74VHC08F LOGIC IC 1 MAIN
IC7 M5218AL OPAMP 1 AS
IC7 TC7SH08FU LOGIC IC 1 MAIN
IC8 K16V1204CTL6 DRAM16M 1 MAIN
IC8 M5218AL OPAMP 1 AS
IC9 SVIGM5238L OPAMP 1 AS
IC11 M29LV160B8TN PROGRAMED FLASH MEMORY 1 MAIN
IC12 QSIGX3C64016 MASK-PRG 1 MAIN
IC14 BR93LC56RFE2 EEPROM 1 MAIN
IC15 K16V1204CTL6 DRAM16M 1 MAIN
IC16,17 T74VHCT374AF D TYPE FF 2 MAIN
IC18 TC7W32FU 2 INPUT OR GATE 1 MAIN
IC19 TC74VHC139F 2 TO 4 DECORDER 1 MAIN
IC101 D72070GF3BE MICRO CONTROLER 1 MAIN
IC102 TC7WT241FU DUAL 3 STATE BUFFER 1 MAIN
IC103 TC7S14FT85L SCHMIT TRIGGER INVERTER 1 MAIN
IC104 TC7WT241FU DUAL 3 STATE BUFFER 1 MAIN
IC105 TC7SU04FT85L INVERTER 1 MAIN
IC106 TC74LCX245F BUS BUFFER 1 MAIN
IC107 TC7SH08FU 2 INPUT AND GATE 1 MAIN
IC108 T7SET04FT85L BUS TRANSCEIVER 1 MAIN
