Technics SX-PR603 - Page 46

Ref. No. Part No. Part Name & Description Pcs Remarks
IC109 M5M34051FPE2 BUS TRANSCEIVER 1 MAIN
IC110 T74VHCT541AF CMOS 1 MAIN
IC111 M66273FP LCDC 1 MAIN
IC112 T74LCX16244A CMOS 1 MAIN
IC201 M51V18165D70 DRAM16M-EDO 1 MAIN
IC202 TC7SU04FT85L LOGIC 1 MAIN
IC203 TMS57070FFT DSP 1 MAIN
IC204 PCM1734EA-E2 DAC 1 MAIN
IC206 M5218AFPE3 OPAmp 1 MAIN
IC207 BA10393F-E2 Comparator 1 MAIN
IC208 M5218AFPE3 OPAmp 1 MAIN
IC209 MN1382CTX RESET-IC 1 MAIN
IC301 D82398GD001 TONE GENERATOR 1 MAIN
IC302,03 T7SZ32FUT85L 2 INPUT OR GATE 2 MAIN
IC304 QSIGX3C64014 MASK-ROM 1 MAIN
IC305 QSIGX3C64013 MASK-ROM 1 MAIN
IP3,P4 ICP-N75T104 IC PROTECTOR 2
AS
IP5,P6 ICP-N10T104 IC PROTECTOR 2
AS
IP7,P8 ICP-N75T104 IC PROTECTOR 2
AS
IP101,02 ICP-N10T104 IC PROTECTOR 2
MAIN
JK1 QJJG010AA JACK HEADPHONE 1 JACK2
JK1 QJSG007AA PEDAL IN 1 JACK
JK1 SJVD0203B AC INLET 1
ACP
JK2 QJJG010AA JACK HEADPHONE 1 JACK2
JK2 QJSG018AA COMPUTER 1 JACK
JK3-K5 QJSG016AA MIDI THRU 3 JACK
JK6-K9 QJJG003AA LINE OUT L 4 JACK
JP1 ERJ6GEY0R00V CHIP JUMPER 1 MAIN
JP5,P6 ERJ6GEY0R00V CHIP JUMPER 2 MAIN
JP202 ERJ6GEY0R00V CHIP JUMPER 1 MAIN
JP301 ERJ6GEY0R00V CHIP JUMPER 1 MAIN
L1 QLBG005A COIL 1 AS
L1 QLBG005A COIL 1 MAIN
L1 QLQGT2T100SA 10UH × 2 1
ACP
L1 QLQGT3T131TA 130UH × 3 1 JACK
L1 QLQGT3T131TA 130UH × 3 1 JACK2
L2 QLBG005A COIL 1 AS
L2 QLBG005A COIL 1 MAIN
L2 QLQGT3T131TA 130UH × 3 1 JACK
L3 QLBG005A COIL 1 AS
L3 QLQGT3T131TA 130UH × 3 1 JACK
L4 QLBG005A COIL 1 AS
L4,L5 QLQGT3T131TA COIL 2 AS
L5 QLQGT3T131TA 130UH × 3 1 JACK
L6 QLQGT1B800MA 80UH 1
AS
L6 QLQGT3T131TA 130UH × 3 1 JACK
L7 QLQGT1D600MA COIL 1 AS
L7 QLQGT3T131TA 130UH × 3 1 JACK
L8 QLQGT1D600MA COIL 1 AS
