Technics SX-PR700 User Manual

ONE TOUCH PLAY |
PIANO STYLIST
TECHNI-CHORD
PANEL MEMORY
SEQUENCER
COMPOSER
MEMORY & CONTROL
SOUND-SETTING
MIDI
EXTERNAL MEMORY
DISPLAY
TERMINALS
OUTPUT
SPEAKERS
POWER REQUIREMENT
DIMENSIONS (W x H x D)
NET WEIGHT
ACCESSORIES
© (ONE TOUCH PLAY/MUSIC STYLE SELECT)
2 BANKS (A/B) x 5, SET
16 TRACKS
RESOLUTION : 96 PULSES PER QUARTER-NOTE
STORAGE CAPACITY : APPROX. 30000 NOTES (10 SONGS MAX.)
INPUT MODES : EASY RECORD, REALTIME RECORD, STEP RECORD
FUNCTIONS : TRACK ASSIGN, EDIT, SONG SELECT/NAME, PUNCH RECORD, MEDLEY
5 PARTS : BASS, ACCOMP 1, ACCOMP 2, ACCOMP 3, DRUMS
STORAGE CAPACITY : APPROX. 10000 NOTES
INPUT MODES : EASY COMPOSER, REALTIME RECORD, STEP RECORD
FUNCTIONS : COMPOSER CHORD MAP, MODE SELECT, PATTERN COPY, LOAD SINGLE COMPOSER PATTERN, SEQ TO COMP COPY,
COMPOSER LOAD
MEMORY : 3 BANKS X 10 (VARIATION 1-4, INTRO 1, 2, FILL IN 1, 2, ENDING 1, 2)
INITIAL, DISK LOAD, DISK SAVE, DIRECT PLAY, PEDAL SETTING, FLOPPY DISK FORMAT, MEDLEY, PANEL MEMORY MODE,
MUSIC STYLE ARRANGER MODE
PART SETTING (VOLUME, PAN, EFFECT, SUSTAIN, KEY SHIFT, TUNING, PITCH BEND RANGE, OTHERS), MIXER,
OVERALL TOUCH SENSITIVITY, MASTER TUNING, KEY SCALING, TECHNI-CHORD TYPE, LEFT HOLD, REVERB SETTING,
DSP EFFECT SETTING
BASIC CHANNEL, CONTROL MESSAGE, OCTAVE SHIFT & LOCAL ON/OFF, REALTIME MESSAGES, COMMON SETTING,
MIDI PRESETS, INPUT/OUTPUT SETTING, GENERAL MIDI, P. MEM OUTPUT
BUILT-IN 3.5 inch FLOPPY DISK DRIVE FOR 2HD (1.44 MB), 2DD (720 KB)
LCD (320x240 DOTS )
PAGE, CONTRAST, EXIT, DISPLAY HOLD
PHONES, LINE OUT (R/A+L, L), AUX IN (R/R+L, L), MIDI (IN, OUT, THRU ), PEDAL IN
60Wx 2
16 cmX2, 6.5 cmX 2, MONITOR SPEAKER (13 cm X6 cm) X2
280 W, 185 W (NORTH AMERICA AND MEXICO)
AC120/220/240 V 50/60 Hz
AC120 V 60 Hz (NORTH AMERICA AND MEXICO)
AC230-240 V 50/60 Hz (EUROPE, AUSTRALIA, NEW ZEALAND AND PHILIPPINES)
139.7 cm X 105 cm X 61.4 cm (55"X 41-11/32" X 24-3/16")
76 kg (167.6 Ibs.)
STAND, AC CORD
*Specifications are subject to change without notice for further improvement.
WARNING
To prevent the risk of fire, smoke, or electrical shock and to ensure safe operation, please be sure to follow the safety guidelines
below.
—
. At places where special caution is required, the necessary safety precautions are clearly labeled or printed, for example, on the
cabinet, or on the part concerned. Please follow these safety precautions, and also those listed in the Owner's Manual.
he
. Parts which have a /\ mark in the circuit diagram or in the parts list are essential for safety. When replacing these parts, be
sure to use only the specified parts.
ao
&
. Use the specified types for internal wiring (double-insulated wiring, etc.).
. When replacing parts on the AC primary side (power transformer, electric switch, electrical cord, noise-prevention condenser,
etc.), wind the lead wire and secure it by soldering.
oa
o
N
place.
[es]
. Spacing
. Do not let the wiring come into contact with heat-emitting devices (fuse resistor, radiator plate, etc.).
. When replacing the wiring, make sure that it is not in contact with the unfinished or rough edge of a part.
. When replacing the power cord (except for the plug-in type), tug it from various directions to confirm that it does not slip out of
If soldering was done on the AC primary circuit, confirm that the interval between the soldered terminals or between the terminal
and surrounding metallic parts is at least the minimum required (between the primary circuit and the chassis: at least 6.5 mm;
between primary circuit terminals: at least 4.0 mm; between primary circuit terminals and secondary circuit terminals: at least 6.5
mm).

Technics SX-PR700 Specifications

General

Brand	Technics
Model	SX-PR700
Category	Musical Instrument
Language	English
