Fuel Selector Valve
Figure 11.10
TAE EPA 20-2820-H0071 01
label set,
fuel selector
30.2 gal
C172 F, G, H
15.1 gal 15.1 gal
LEFT RIGHTBOTH
114.4 ltr 57.2 ltr 57.2 ltr
STANDARD TANKS
40.2 gal 20.1 gal 20.1 gal
LEFT RIGHTBOTH
152.2 ltr 76.1 ltr 76.1 ltr
LONG RANGE TANKS
31.7 gal 15.85 gal 15.85 gal
120 ltr 60 ltr 60 ltr
C172 I, K, L, M
33.6 gal 16.8 gal 16.8 gal
127.4 ltr 63.7 ltr 63.7 ltr
C172 N, P
41.9 gal 20.9 gal
20.9 gal
158.6 ltr 79.3 ltr 79.3 ltr
44.6 gal 22.3 gal 22.3 gal
168.8 ltr 84.4 ltr 84.4 ltr
C172 R, S
98.4 ltr
26 gal26 gal52 gal
98.4 ltr196.8 ltr
C172 P
integral tank
106 ltr
14 gal
53 ltr
14 gal
53 ltr
28 gal
