User Guide
11
Component Input (YPbPr cables)
You can connect this TV to a compatible device using YPbPr cables. Connect the red, green and
blue outputs to the matching coloured inputs on the compatible device. An additional audio input
is required.
Wall Mounting
1. The base must fi rst be removed. Place the TV face down.
2. Remove the two screws holding the base in position.
3. Remove and store the base and screws.
4. Use four machine screws to mount the TV on the bracket.
This unit is VESA-compliant and designed to be wall-mounted with a VESA-compliant
100mmx100mm mounting kit. Mount this unit according to the instruction of the wall bracket (not
supplied).
Tesco-Tecknika IDTV .indd Sec1:11Tesco-Tecknika IDTV .indd Sec1:11 07/07/2009 16:51:5207/07/2009 16:51:52
