Installation
Anti-tilting chains - CORRECT Installation
33
Once the holes have been drilled, the chains can be fed through
and the upright can be fitted into position.
The chains then need to be pulled as tight as possible from inside
the cabinet while at the same time being fixed to the rear of the
cabinet using a self drilling wood screw. It is better to have the
screw fixed closer to the hole for better support. The left and right
side examples shown have two extra screws attached to the chain
which makes the installation neater by keeping the chain off the
shelf away from the gas and electricity supply, they will also
provide added support.
At this point the oven will be secured in location and will not move
forward at all. It is recommended that all upright oven chains be
fitted this way.
Installation forms part of the installers compliance and that in line
with the AGA regulations chains are designed to be installed to
prevent cooker from tilting. They are not designed to replace
parental supervision when the cooker is in use.
Chain fixed in
two locations
Chain fixed in
two locations
LEFT SIDE RIGHT SIDE
