Installation
Anti-tilting chains - CORRECT Installation
32
In order to prevent the oven from tipping forward as shown on the
previous page, we need to make sure both chains provided with
the oven are used.
On the left side of the oven,
a 16mm drill bit was used to
drill through the cabinetry
into the adjacent cabinet, as
you can see the hole has not
been drilled hard up against
the wall because there is a
16mm board at the rear of
the cabinet. The height of the
hole from the floor is level
with where the chain
attaches to the oven.
The right side has been
drilled much the same. A
new hole has been drilled
below the gas and power
supply hole.
LEFT SIDE RIGHT SIDE
Hole and
chain level
