TechniSat DIGIT S3 DVR User Manual

99
DE
EN
When entering channel numbers with multiple digits, you have approx. three
seconds aer pressing a key to enter the next number. If you wish to enter a
number consisting of only one, two or three digits, you can speed up the entry
procedure by keeping the key OK pressed a lile longer on the last digit.
7.3.3 Using the navigator (channel list)
> Press the OK key.
The channel list navigator now appears. In TV mode only TV channels will be
shown, and in Radio mode only radio channels appear.
The channel currently selected is highlighted.
> You can view additional data about the current programme by pressing the
INFO key.
7.3.4 Selecting the channel
> You can now highlight the desired channel using the up/down arrow keys,
the page up/down and the number keys.
> Press the OK key to select the highlighted channel.
Digit S3 DVR_V2.indd 99Digit S3 DVR_V2.indd 99 23/02/2022 08:5323/02/2022 08:53

TechniSat DIGIT S3 DVR Specifications

General

Tuner type	Digital
Demodulation	QPSK
Product color	Black
Number of tuners	1 tuner(s)
Audio output channels	- channels
On Screen Display (OSD)	Yes
Electronic Program Guide (EPG)	-
Digital Satellite Equipment Control (DiSEqC)	1.0, 1.2
Package weight	994 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	6.2 W
Video codecs	H.264
Cables included	HDMI
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Signal source	Cable, Ethernet (RJ-45), Satellite
Digital signal format system	DVB-S, DVB-S2

Weight and Dimensions

Depth	130 mm
Width	180 mm
Height	44 mm
Weight	380 g
