6 Assembling the TECHNIMAX AS1
6.1 Aaching / detaching the LED motorised brush and aluminium suction tube
Aaching:
The aluminium suction tube (7) is plugged directly into the suction opening
in the motor unit. It must engage audibly. Aach the LED motorised brush
(12) to the aluminium suction tube in the same way.
Detaching:
Press the release buon (A) on the motor unit or on the aluminium suction
tube (B) and pull the LED motorised brush or the aluminium suction tube out
at the same time.
A
B
Motor unitAluminium suction tubeFloor brush
6.2 Aaching/detaching the 2-in-1 combination nozzle and crevice tool
Aaching:
Insert the desired nozzle into the suction opening in the motor unit or
the aluminium suction tube (7). Make sure that the catch on the nozzle is
pointing towards the respective release buon. The nozzle must engage
audibly.
Detaching:
Press the release buon (A) above the suction opening or on the aluminium
suction tube (B) and pull the nozzle out at the same time.
6.3 Detaching / aaching the dust holder
Detaching:
Push the release buon (3) on the dust holder (4) and remove it upwards.
