3.4: Preparing a G-Code File
The G-code le must be copied into the programs folder on the PLC directory.
There is a shortcut to this on the main desktop.
- Drag your les from the USB to the desktop icon or copy and paste.
- Files must be no more than 8 characters in length.
Folders can be copied in to the programs folder, but make sure the le G600 is in the
same folder as your le.
This data must be in the G-code le. If the correct post to Techno Osai HDS machine is
used in the CAM package, then it will be entered automatically.
Data For a Techno Osai G-code File.
Start of File:
G70 (Programming in Inches)
G90 (Absolute Programing)
G40 (Disables Cutter Diameter compensation)
G80 (Disable Can Cycles)
G17 (Circular interpolation on XY plane)
G27  (Continuoussequenceoperationwithautomaticspeedreductiononcorners)
M143 Edge Pop Up Pins Down)
M49 (Dust shroud down)
G600  (Loadsasetofparametersintocontrollersampliers.
  ThisisatxtlethatneedstobeinthedirectoryoftheG-codele.)
(UAO,01) (Applies Origin 1 to machine coordinates.
Ideally user will have an option to select Origin number 1-5)
Tool Changes:
T1 M6 (Standard Tool change command)
M3 S18000 (Spindle on and RPM value)
(DLY,05) (Wait 5 seconds for spindle to achieve set speed)
G27  (Applycontinuoussequenceoperationwithautomaticspeedreduction)
Circles:
G02 (Clockwise with Arc Center (I-J) Absolute)
G03 (Anti-Clockwise with Arc Center (I-J) Absolute)
R is also accepted, but I-J’s must be Absolute.
(Continued on next page)
