Pneumatic connection
Connect filtered and de-humidified compressed air to the special rapid connector AC (see please page 9)
located on the rear of the machine at the top.
The compressed air must be at least 7 Bar in pressure.
The quantity of air required: suction of 11 liters per minute
“Ice-cream mixture” connection
As indicated on page 5, connect a rubber pipe with internal diameter 25 mm and max. 4 metres in length to
point H (rubber holder supplied with machine).
NB Do not use a rigid steel tube
If the maturation tank from which the mixture is taken is over 4 metres away, it is possible to deliver the
mixture using a pump providing the pressure of the mixture on arrival does not exceed 0.5 Bar.
If the pipe leading to the machine is made of steel, the last half metre of pipe must be rubber.
