Technogel MIXTRONIC 110 - Electrical Installation

11
⇒ Electric installation
The electrical installation, which the machine is connected to, must be carried out by a skilled electrician
according to regulations and observing the Laws in force. An efficient electrical installation with earthing is
the most important thing in order for your machine to work perfectly.
Install an adequate wall switch; we highly recommend an automatic differential switch.
See Table (A) for energy and adsorption details.
Verify that the mains voltage is suitable for the machine; this is written on the data plate (See page 9).
The line cable of the machine has four wires when the machine is a 220 V.
When the cable has four wires, the yellow/green wire is the earth and the other three are the three phases.
Table (A):
MIXTRONIC 60
V.220
60HZ
Potenza totale kW.
6.6
Assorbimento max. A. 20
Cavo di linea
N° fili e sezione
4 x AWG 10
MIXTRONIC 110
V.220
60HZ
Potenza totale kW.
14
Assorbimento max. A.
52
Cavo di linea
N° fili e sezione
4 x 6
mm²
It is advisable to verify the efficiency of your electricity supply , especially regarding the
earth and safety systems.
TECHNOGEL spa TAKES NO RESPONSIBILITY FOR ACCIDENTS CAUSED
BY IMPROPER INSTALLATION OR FAULTY WIRING.
