Dismantling the Stirrer: MIXTRONIC 60 110
A) To dismantle the protection on stirrer (1) turn
anticlockwise and block it. Remove by lifting upwards.
B) Remove the white delrin top (2).
C) Remove the stirrer (3) by lifting upwards.
Clean the interior of stirrer (3) using the cleaning device
supplied.
When re-assembling the components, take care to match
up cable (4) with drive shaft (5) on the machine..
CAUTION !!
THE SHAFT MUST NEVER BE
ROTATED WITHOUT FIRST
DISMANTLING PROTECTION (1).
