Technogym Crossover - Technical Data

15
Crossover
cont.
Technical data
Crossover 700 and 500
Power supply 100÷240 Vac ±10% 50/60 Hz
Maximum braking power 340 W at 120 spm
Minimum braking power 19 W at 60 spm
Mains power input
100 VA max
(160 VA max with Visio)
Fuses 2 x 3.15A (F)
Weight of equipment 155 kg (342 lb)
Maximum user weight 180 kg (397 lb)
Time 0÷999 min ± 1%
Distance 0÷99.99 km ± 5%
Protection grade IP 20
Operating temperature
from +5°C (+41°F)
to +30°C (+86°F)
Electric isolation class Class I
Marks and Certificates CE - UL
(*)
Crossover 700 SP and 500 SP
Maximum braking power 340 W at 120 spm
Minimum braking power 28 W at 60 spm
Weight of equipment 157 kg (346 lb)
Maximum user weight 180 kg (397 lb)
Time 0÷999 min ± 1%
Distance 0÷99,99 km ± 5%
Protection grade IP 20
Operating temperature
from +5°C (+41°F)
to +30°C (+86°F)
Marks and Certificates CE - UL
(*)
(*)
Only if the symbol is present on the equipment identification label.
