3
E
03006011
D
A
99834011
F
B C
Abdominal Crunch
Contents
Description of the equipment
A Seat: where the user sits to perform the exercise.
B Lever: operated by the user by means of the shoulder pads (C).
D Weight stack: the lever (B), operated by the user, moves the weights along two guides
by means of a cable. A pin (E) is used for selecting the load, to adjust the exercise effort
level. The cursor (F) is used to vary the selected workload by 2,5 kg.
Identification of the manufacturer
and equipment
Description of the equipment
Technical data
Accessories
Assembling the number holder
Safety labels and devices
Packing
Place of installation
Unpacking
Lifting and handling the
equipment
Adjusting the equipment
Routine maintenance
Replacing the padded
components
Replacing the cable
Adjusting cable tension
Disassembling the front protective
weight stack panel
Technical Service
Codes for original spare parts
Storage
Disposing of the equipment
Using the equipment
