TECHNOLIFT SL-9 - Parts for Hydraulic Cylinder; Parts for Manual Power Unit (220 V;50 Hz;1 phase)

33
Item Part# Description
Qty.
Note
SL-9
SL-9H
92
10260149
Safety cable
1 0
10206065A 0 1
93
10420045
Washer
14
14
94 10209149 Lock washer 4 4
95 10209152 Ties 4 4
96
10206500B
Parts Box
1
0
10206501B 0 1
Parts for hydraulic cylinder (See Fig.42)
30-1 10209069 O-Ring 2 2
30-2 10209070 Bleeding Plug 2 2
30-3
10209071
Support Ring
2
2
30-4 10209072 Y-Ring 2 2
30-5 10209073 O-Ring 2 2
30-6
11209074
Piston
2
2
30-7 11209075 O-Ring 2 2
30-8 11217076 Piston Rod 2 2
30-9
11209077
Piston Rod Fitting
2
2
30-10
10209078
Dust Ring
2
2
30-11 11209079 Head Cap 2 2
30-12 10209080 O-Ring 2 2
30-13
11209081A
Bore Weldment
2
2
Parts For manual Power Unit, 220V/50Hz/1phase (See Fig.43)
1 71150019 AMGO Label 1 1
2 81400300 Cross half round head screw 2 2
3 81400363 Motor connecting shaft 1 1
4 81400362 Manifold block 1 1
5 10209149 Washer φ6 4 4
6 81400276 Inner hexagon iron plug 1 1
7 81400259 Red plastic plug 1 1
8 85090142 Hex bolt 4 4
9 81400292 Gear pump 1 1
10 81400294 Release valve 1 1
11 10209034 Washer φ8 2 2
12
81400029
5
Hex bolt 2 2
13 81400365 O-ring 1 1
14 10209152 belt 1 1
15 85090167 Magnet 1 1
16 81400290 Filter net 2 2
17 81400453 Aluminum alloy motor 1 1
18 41030055 AC contractor 1 1
19 81400088 Running capacitance 2 2
20 81400130 Starting capacitance 2 2
