Item Part# Description
Qty.
Note
209C 209CH
13 81400365 O ring 4 4
14 10209152 belt 2 2
15 85090167 Magnet 1 1
16 81400290 Filter net 1 1
17 81400439 Aluminum alloy motor 1 1
18 10420070 Push button 1 1
19 81400348 AC contractor 1 1
20 81400286 Cover of Motor Terminal Box 1 1
21 10420148 Cup Head Bolt With Washer 1 1
22 81400296 Screw nut 1 1
23 81400459 Throttle valve core 1 1
24 10209069 O-ring 1 1
25 81400266 Relief valve 1 1
26 81400284 Inner hexagon iron plug 1 1
27 81400452 Elastic shaft pin 1 1
28 81400451 Relief handle 1 1
29 10209020 Plastic ball with rack handle 1 1
30 81400125 Relief screw nut 1 1
31 81400124 Relief valve spacer 1 1
32 81400450 Valve seat( high) 1 1
33 81400443 Relief valve 1 1
34 81400267 Checking valve 1 1
35 81400288 Oil suction hose 1 1
36 81400289 Oil return hose 1 1
37 81400364 Hose clamp(stainless steel) 1 1
38 81400263 Oil tank cover 1 1
39 81400275 Oil tank 1 1
Order original parts when required from
GRAND PRIX IMPORT at 1-800-361-4095
