TECHNOLIFT SL-9L - Lifting Arms and Lock Adjustment

14
Floor Cover
M. Assemble floor cover (See Fig. 22).
N. Install lifting arms and adjust the arm locks
1. Install the lifting arms
(See Fig. 23, 24)
Fig. 23
Snap Ring
Use the 8
#
socket head
wrench to loosen the
socket bolt
Fig. 24
Spanner loose screw
Fig.２２
