6
5. Open the carton of parts and check the parts according to parts box list
(See Fig. 10).
D. Position powerside columns
Lay down two columns on the installation site parallelly, position the powerside
column according to the actual installation site. Usually, it is suggested to install
powerside column on the front-right side from which vehicles are driven to the lift
(See Fig. 11).
Fi
g. 11
using M10*35 hex
bolt with nut and lock
To Next Page
