technoswitch ORYX200 Series - Circuit & Interface Specifications

ORYX202 ORYX204 ORYX208 Conventional Fire Panels – INSTALLATION & OPERATION MANUAL
PRMAN-0047 ORYX200 S21 Fire Panel Range Rev 02.00 220224.docx E&OE
- 5 -
Item
Specification Detail
AUX Supply Output
24 V DC, 0.5 A
Battery Capacity
- ORYX202, ORYX204
- ORYX208
24 V 7 Ah
24 V 7 Ah, 12 Ah or 17 Ah
Battery Charging Current
0.5 A max temperature compensated
Number of Fire Zones
2, 4 or 8 Zones
Zone EOL
3k3 Ω
Zone Alarm Thresholds
220 to 900 Ω
Sounder Outputs
2x rated at 27.5 V DC, 0.3A each
Sounder EOL
3k3 Ω
General Fire Relay
30 V AC/DC, 1 A maximum
General Fault Relay
30 V AC/DC, 1 A maximum
Programmable Relays
- ORYX202
- ORYX204
- ORYX208
2 rated 30 V AC/DC, 1 A maximum
4 rated 30 V AC/DC, 1 A maximum
8 rated 30 V AC/DC, 1 A maximum
Programmable Inputs
2x fully monitored as per below
Monitored Inputs EOL
3k3 Ω
Monitored Inputs Alarm Threshold
220 to 900 Ω
L-Bus Topology and Distance
RS485 ring network @ 1,200 metre max
L-Bus Cable
PH30 or PH120, Twisted pair screened cable with a core resistance of
18.1 ohm/km
Number of Repeaters on L-Bus
7 (Seven)
The range also offers 2, 4, and 8 Zone ORYX Repeater Panels in either ABS or IP65-rated Weatherproof enclosures.
