ORYX202 ORYX204 ORYX208 Conventional Fire Panels – INSTALLATION & OPERATION MANUAL
PRMAN-0047 ORYX200 S21 Fire Panel Range Rev 02.00 220224.docx E&OE
- 4 -
SPECIFICATIONS
Item
Specification Detail
Part Number
Part Description
- ORYX202
ORYX 2 Zone FACP in ABS Enclosure
- ORYX204
ORYX 4 Zone FACP in ABS Enclosure
- ORYX208
ORYX 8 Zone FACP in Metal Enclosure
- ORYX202-W
ORYX 2 Zone FACP in Weatherproof Enclosure
- ORYX204-W
ORYX 4 Zone FACP in Weatherproof Enclosure
- ORYX208-W
ORYX 8 Zone FACP in Weatherproof Enclosure
- ORYX202-WDIN
ORYX 2 Zone FACP in Weatherproof Enclosure c/w DIN Rail
- ORYX204-WDIN
ORYX 4 Zone FACP in Weatherproof Enclosure c/w DIN Rail
- ORYX208-WDIN
ORYX 8 Zone FACP in Weatherproof Enclosure c/w DIN Rail
Enclosure
- ORYX202 & ORYX204 ABS
- ORYX202 & ORYX204 Weatherproof
- ORYX208 Standard
- ORYX208 Weatherproof
ABS: Two-tone (White lid with Anthracite Grey RAL 7016 base)
Mild Steel IP65: Matt Light Grey (ANP 37035)
Mild Steel IP30: Matt Light Grey (ANP 37035)
Mild Steel IP65: Matt Light Grey (ANP 37035)
Dimensions H x W x D (mm)
- ORYX202 & ORYX204 ABS
- ORYX202 & ORYX204 Weatherproof
- ORYX208 Standard
- ORYX208 Weatherproof
270 x 330 x 125
450 x 390 x 143
394 x 398 x 128
500 x 450 x 139
Environmental
–5 °C to +40 °C
Humidity
95% RH, Non-condensing
Weight
- ORYX202 & ORYX204 ABS
- ORYX202 & ORYX204 Weatherproof
- ORYX208 Standard
- ORYX208 Weatherproof
± 2.1 kg (excl. Batteries)
± 7.4 kg (excl. Batteries)
± 5.7 kg (excl. Batteries)
± 10.7 kg (excl. Batteries)
Cable Entries
- ORYX202 & ORYX204 ABS
Top: 6x 20 mm; 5x 25 mm
Back: 4x 20 mm; 2x 25 mm
- ORYX202 & ORYX204 Weatherproof
Bottom: 5x 20 mm; 2x 25 mm
- ORYX208 Standard
Top: 10x 20 mm; 8x 25 mm
Back: 5x 20 mm; 7x 25 mm
- ORYX208 Weatherproof
Bottom: 5x 20 mm; 4x 25 mm
LED Indicators
- ORYX202
- ORYX204
- ORYX208
3x Fire, 13x Fault (8 Hidden below lid), 8x Control & Information indications
5x Fire, 15x Fault (8 Hidden below lid), 8x Control & Information indications
9x Fire, 19x Fault (8 Hidden below lid), 8x Control & Information indications
Key Switch
Enable Controls
Event Log
1000 log events
Mains Supply
Quiescent Load
- ORYX202
- ORYX204
- ORYX208
Alarm Load
- ORYX202
- ORYX204
- ORYX208
100 – 240 V AC (± 10%), 50/60 Hz, 1.0 A max
56 mA @ 110 V AC/45 mA @ 240 V AC
95 mA @ 110 V AC/65 mA @ 240 V AC
115 mA @ 110 V AC/76 mA @ 240 V AC
160 mA @ 110 V AC/56 mA @ 240 V AC
182 mA @ 110 V AC/105 mA @ 240 V AC
230 mA @ 110 V AC/130 mA @ 240 V AC
Power Supply
27.5 V DC, Switch Mode, 1.2 A load, 0.5 A max battery charging
PCB Quiescent Load
- ORYX202
- ORYX204
- ORYX208
70 mA @ 27.5 V DC
90 mA @ 27.5 V DC
108 mA @ 27.5 V DC
PCB Alarm Load
- ORYX202
- ORYX204
- ORYX208
265 mA @ 27.5 V DC
385 mA @ 27.5 V DC
410 mA @ 27.5 V DC
