Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
2.1 User Manuel VPS RF Model
2.1.1 Seng the Room Thermostat
Press the receiver buon for more than 3 seconds, unl the indicator light begins to ash. Subsequent-
ly press the transmier key in the conguraon mode. (see User Manual Receiver) As soon as the indi-
cator light stops ashing the two products are assigned.
2.1.2 Seng the sender
Press the receiver buon for at least 3 seconds unl the indicator light starts ashing.
Two modes of operaon are possible.
Slow ashing: On\O switch
Fast ashing: insgator
To switch the mode again, press the key briey. Take the transmier into the Conguraon mode (see
user manual transmier). Check that the indicator light is no longer ashing.
Applicaon Example
The use of a room thermostat in combinaon with a opening detector is ideal, because the opening de-
tector will detect if a window is open and will automacally switch to frost protecon. By pressing the
receiver buon for approximately 10 seconds, you can change the relay´s seng. You know the seng
is changed as soon as the signal light stops ashing.
2.1.3 Deleng Allocaons
To delete the seng simply press the receiver key for approximately 30 seconds unl you see the recei-
ver light ash briey. All transmiers are now deleted.
2.1.4 Receiver RF- Technical Specicaons
• Power Supply 230 V, 50 Hz +/-10%
• Protecon Class II
• Expenditure : 0,5 VA
• Switching capacity max.: 16 A 230 Ve Cos j =1 or max. 300 W with lighng control
• Radio Frequency 868 MHz (NormEN 300 220),
• Radio Range up to 300 m in an open eld, indoors up to ca. 30m, depending on the construcon of
the building and the electromagnec interference
• Maximal Number of receivers: 8
• Mode of operaon: type 1.C (Micro-disconnecon)
• Operang Temperature: -5°C to +50°C
• Storage Temperature: -10 °C +70°C
• Dimensions: 120 x 54 x 25 mm
• Degree of Protecon : IP 44 - IK 04
• To be installed in average polluted Areas4. Installaon DSM Thermoastat / DAS Schnistelle.
