6.1 Assembly instrucon
This Manual is very important and has to be kept at a safe place at all mes. Be sure to hand this ma-
nual to any other succeeding owner of the device. The device comes with a power plug that has to be
plugged into an outlet.
The device is designed to be connected to 230V (nominal) alternang current (AC).
7.1 Wall Installaon
When installing the device, the safety distance must be strictly adhered to, so that ammable materials
can not ignite. Install the device to a wall which is heat resistant up to 90 ° C.
• Due to possible re hazard the safety distances are observed during assembly:
Side walls of the heater to any masonry: 5 cm
Side walls of the heater to combusble materials: 10 cm
Distance radiator to the oor: 25 cm
arranged spaced upper radiator limit to about components or covers (. Eg window):
ammable 15 cm
nonammable 10 cm
To prevent inammable materials from catching re be sure to keep the prescribed safety distance
when installing the device. Mount the device to a wall that is reproof up to 90 °C.
The safety distance to the oor should be 25 cm, and at least 10 cm to all other devices. Furthermore
there has to be safety distance of approximately 50 cm between the venlaon grille, windowsills, roof
slopes and ceilings.
If you want to install the device in your bathroom, be sure to keep it out of reach for people taking a
shower or a bath.
When mounng the device to the wall, be sure to keep to the dimensions as indicated in the illustraon
on page 11. Drill two or three (if available) 7 mm holes and aach the corresponding plug. Then screw
the 4 x 25 mm screws into the holes, leaving a distance of 1-2mm between the head of the screw and
the wall.
Hang the device in the two or three ngs and ghten it down. See also the addional mounng infor-
maon at the following pages!
