Techwell,Inc. TW8816 Evaluation Board User’s Manual
Examples
Change address:
[8A]>C 98
address : 98
[98]>
Dump registers:
[8A]>d 0
Read [Adrs:8Ah,00h] 0Ah
Read [Adrs:8Ah,01h] 83h
Read [Adrs:8Ah,02h] 68h
Read [Adrs:8Ah,03h] 20h
Read [Adrs:8Ah,04h] 00h
Read [Adrs:8Ah,05h] AFh
Read [Adrs:8Ah,06h] 40h
Read [Adrs:8A,07h] 02h
[8A>
Read register
[8A]>r 2
Read [Adrs:8Ah,02h] 68h
[8A]>
Write register
[8A]>w 2 60
Write 60h to [Adrs(8Ah)Index(02h)] Read [Adrs:8Ah,02h] 60h
[8A]>
Register++, Register— (by pressing ”>” and “<” button)
[8A]>r 10 // Read or write once.
Read [Adrs:8Ah,10h] 00h // [>] increase(++)
Write 01h to [Adrs(8Ah)Index(10h)] Read [Adrs:8Ah,10h] 01h // [>] increase(++)
Write 02h to [Adrs(8Ah)Index(10h)] Read [Adrs:8Ah,10h] 02h // [>] increase(++)
Write 03h to [Adrs(8Ah)Index(10h)] Read [Adrs:8Ah,10h] 03h // [>] increase(++)
Write 04h to [Adrs(8Ah)Index(10h)] Read [Adrs:8Ah,10h] 04h // [>] increase(++)
Write 05h to [Adrs(8Ah)Index(10h)] Read [Adrs:8Ah,10h] 05h // [<] Decrease(--)
Write 04h to [Adrs(8Ah)Index(10h)] Read [Adrs:8Ah,10h] 04h // [<] Decrease(--)
Write 03h to [Adrs(8Ah)Index(10h)] Read [Adrs:8Ah,10h] 03h
[8A]>
Repeat previous command (by pressing “/” button)
[8A]>r 2
Read [Adrs:8Ah,02h] 60h
[8A]> // [/]
Read [Adrs:8Ah,02h] 60h
[8A]>
Version 1.00 9/25/2007
