Notice of battery use
• Do not put PAPR unit with power-on in the package. It’s better to remove the battery from
the body when put in the package.
• Do not keep PAPR unit inside the car in hot summer season.
• Do not throw or give the high impact to PAPR unit.
• Do not put PAPR unit on the electric heat generating equipment.
• Do not use any other battery charger.
• Standard battery operation time:
9 hours at low speed (170+lpm), 5 hours at high speed (210+lpm).
• Battery storage temperature: 14°F to 115°F (-10°C - 45°C), R.H.< 85%
Breathing tube
O-ring
fig.7a fig.7b
fig.7dfig.7c
BREATHING TUBE
Assembling
Insert the two prongs on the breathing tube
into the blower unit and helmet air duct (See
fig.6), twist 1/4 to the anti- “open” direction
(See fig.7a / 7c), then clip the breathing tube
into holder on the back cover of the headgear
to lock into place (See fig.8).
Disassembling
Twist 1/4 to the “open” direction and then take
the prongs out from the blower unit and
helmet air duct (See fig.7b / 7d).
WARNING
Always inspect the PAPR end of the breathing tube to confirm the rubber O-ring is in place, see fig.7a. Replace if
missing or damaged.
Be sure tube is properly installed and non-filtered air cannot enter the facial.
fig.6
fig.8
7
Assembling from blower Disassembling from blower
Assembling from helmet Disassembling from helmet
